EB-PQ2216B

Monday to Friday 9:00 to 18:00 HKT

Compact & Premium Large Venue 4K Laser Projector

Designed to engage and captivate audiences with ultra-high resolution, large format content, EB-PQ2216B uses 3LCD technology to deliver outstanding colour reproduction, while Epson's patented 4K Crystal Motion technology offers stunning image quality. Affordable and energy-efficient, EB-PQ2216B also features interchangeable lenses, a light and compact design and extensive connectivity.

      • 16,000 lumens Colour and White brightness
      • 4K Crystal Motion technology
      • Filter-less cabinet for low-maintenance operation
      • HDR support & Scene Adaptive Gamma Correction
      • Simplified installation with 9 optional powered lenses
      • With “Edge Blending” feature
  • Model: V11HB04880

Specifications Projector:


Keystone Correction: Vertical: ±45 degrees; Horizontal: ±30 degreesColor Reproduction: Up to 1.07 billion colorsContrast Ratio: Over 5,000,000:1Projection System: RGB liquid crystal shutter projection systemDriving Method: Epson Poly-silicon TFT Active MatrixColor Brightness - Color Light Output: 16,000 lumensWhite Brightness - White Light Output: 16,000 lumensAspect Ratio: 16:10Native Resolution: Resolution on Screen: 4K (3840 x 2160)Laser Type: Laser DiodeLight Source Life: 20,000 hours (Normal Mode)

Power:


Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz ACPower Consumption: Normal Mode: 1,114 W

General:


Weight: 29.2 kg

Projection Lens:


Type: Powered shift/focus/zoomF-number: (ELPLM15) 2.0 - 2.1Focal Length: (ELPLM15) 14.8mm - 17.7mmLens Shift: (ELPLM15) Vertical: ±60% / Horizontal: ±18% Zoom Ratio: (ELPLM15) Optical Zoom: 1.0 – 1.6

General Projector (Projector Details):


Interfaces: 12G-SDI In/Out, HDMI (HDCP 2.3) x 2/HDMI Out x 1, HDBaseT x 1
Variable Audio Out: Mini Stereo x 1, USB Type-B x 1, USB Type-A x 2 (5 V, 2.0 A), USB Type-A for Wireless LAN (optional)
Serial: RS-232c x 1 (9-pin), Remote Stereo Mini, Network: RJ-45Fan Noise: Normal mode: 44 dB

Dimensions Projectors:


Excluding feet: 586 x 185 x 492 mm (W x H x D)
