TM-T88VI POS Receipt Printer
TM-T88VI POS Receipt Printer

Revolutionary receipt printer with advanced connectivity and cloud support

Revolutionizing POS, the OmniLink TM-T88VI helps merchants deliver the best customer experience. Featuring multi-interface connectivity, it meets needs both now and in the future. With built-in Ethernet and USB, plus Bluetooth® and wireless options, the TM-T88VI supports traditional PC-POS, mobile devices and cloud servers. Print from web-based applications using Epson's ePOS™ Print Technology. Or, utilize Server Direct Printing for online ordering. Epson's beacon support provides distributed proximity-based printing1. And, NFC enables Bluetooth pairing for tablet connectivity and printer selection2.

  • Model: C31CE94371
Where to Buy
CATALOGUE DOWNLOAD
Connect to multiple devices simultaneously — printer can be dynamically shared by legacy POS terminals, tablets and mobile devices, as well as cloud servers
  • Triple-interface connectivity to future-proof growing businesses — maximum flexibility with three options, including built-in USB and Ethernet
  • Print from web-based applications — incorporates Epson's ePOS Print Technology
  • Distributed proximity-based printing — through Epson's beacon support using BLE (Bluetooth Low Energy)1
  • Easy printing from mobile devices — NFC (Near Field Communication) technology for easy pairing with your device2
  • Ultra fast transaction times — print speeds up to 350 mm/sec3, plus a high-speed auto cutter
  • Advanced paper-saving functions — top-margin and character-height reduction features help reduce paper usage by up to 49 percent4
  • Reliability you can count on — printhead life of 200 km, plus an auto cutter life of 3 million cuts5
  • Low total power consumption — operating power of 1.8 A and standby power of 0.5 W

    • Power:

    Power Supply Voltage: 24VDC ± 7%Power Consumption:
  • Operating: Approx. 1.8A (mean)
  • Stand-by: 0.5W
    Power Source: 24VDC ± 7%

    • Print Fonts:

    Character Size:
  • Font A: 1.41 x 3.39
  • Font B: 0.99 x 2.40 (W x H mm)
    Print Fonts:
  • Font A (default): 12 x 24
  • Font B: 9 x 17 (including 2-dot horizontal spacing)
    Column Capacity:
  • 80mm: 42/48/56 columns
  • 58mm model: 30/36/40 columns
    Character Set: 95 Alphanumeric
    18 International
    128 x 43 Graphic (including user-defined page)Fonts:
  • Font A (default): 12 x 24
  • Font B: 9 x 17 (including 2-dot horizontal spacing)
    Barcode: UPC-A/E
    Code 39/93/128
    CODABAR PDF417
    QR-CODE
    MaxiCode
    Data Matrix
    Aztec Code
    Composite Symbology
    GS1-128
    GS1 DataBar Omnidirectional /Truncated /Limited /Expanded

    • Media Handling:

    Thickness: 55 – 80 µmMedia Dimensions:
  • 80mm: 79.5 ± 0.5 (W) x 83mm diameter (3.13" ± 0.02” x 3.27")
  • 58mm: 57.5 ± 0.5 (W) x 83mm diameter (2.26" ± 0.02” x 3.27")

    • Connectivity:

    Standard Connectivity:
  • Built-in USB
    Built-in Ethernet (10/100Base-T/TX) + UIB (Serial
    Parallel
    Powered USB)
  • Wireless (USB wireless dongle): OT-WL02 (802.11 b/g/n)
  • Beacon: Beacon dongle3 (Epson-approved dongle: Laird model BT820)

    Printer Discovery: NFC (Near Field Communication)4
    Simple AP (wireless network)
    Communication Protocols: ESC/POS
    ePOS-Print Service (Ethernet/Wireless)
    Server Direct Print (Ethernet/Wireless)Printing from a Mobile Device:
  • WiFi (802.11): iOS
    Android™ and Windows® operating systems
    Android and Windows

    • Print Other:

    Printing Technology: Thermal line printingPrint Resolution: 180 dpiPrint Speed: Max. 350 mm/sec (13.8”/sec)1 graphics and text;Print Direction: Backward Paper Feeding function: 2mm~14.5mm (0.08”~0.6”)

    General:

    Weight: 1.6 kg (3.5 lbs)Operating Systems:
  • Microsoft® Windows (APD
    OPOS
    OPOS for .NET
    JavaPOS) Mac OS X® Linux (CUPS
    JavaPOS)
  • Microsoft Windows 8.1 / iOS / Android (ePOS-Print SDK)
    Security:
  • Security: WEP
    WPA-PSK
    WPA2-PSK/EAP
  • WPA2-EAP (Enterprise): EAP-TLS
    PEAP/MSCHAPv2
    PAEP/TLS
  • Port open/close setting
  • IP address filtering
    Safety Approvals:
  • Safety standards: UL60950-1/CSA C22.2 No.60950-1
  • EMI standards: FCC/ICES-003 Class A
    Case Color: Epson Black (EBCK)
    Epson White (ENN8.5)Dimensions: 5.71 x 7.68 x 5.83" (145 x 195 x 148mm) (W x D x H)

    • POS General (POS Details):

    Reliability, POS General:
  • MTBF：360,000 hours
  • MCBF: 70,000,000 lines
  • Thermal head life: 200km2
  • Auto Cutter life: 3 million cuts2Data Buffer:
  • Receive: 45 bytes or 4KB
    selectable
  • User-defined: 12KB
  • Macro: 2KB
  • NV graphics: 384KB; NV user: 1KB
    NV Bit Image Memory:
  • NV graphics: 256KB
  • NV user: 1KB
  • Page mode area: 106KD.K.D., POS General: 2 driversSoftware Included:
  • ePOS-Print (XML over HTTP): WEP / WPA / WPA2-Personal/Enterprise
  • ePOS-Display
  • Server Collaboration: Server Direct Print
    Status notification
  • PHP/Sqlite3
  • Backup/Restore: TM Utlity (Win)
    Options: Power supply cover
    PS-180 AC adapter
    one wall hanging bracket
    affixing tape and Connect-It interfaces
    • See Full Specs Hide Full Specs
    Print All Specs

    Notes:

    (1) Requires the use of a beacon dongle connected to TM-T88VI printer via the USB-A port. Supports only Apple® iBeacon™ compliant format. The Epson-approved dongle is Laird model BT820.


    (2) NFC tag requires use of a device that includes NFC reader, and may require additional software.

    (3) Speed based on using 80 mm wide media only and Epson’s PS-180 power supply. Configurations not including the PS-180 will have a default print speed of 300 mm/sec.

    (4) Paper savings depend on the text and graphics printed on the receipt.

    (5) Rated printhead and cutter lives based on use of the following media only, with printer operated at room temperature and normal humidity:

  • Model KT55FA: Papierfabrik August Koehler SE
  • Model PD160R: Oji Imaging Media Co., Ltd.
  • Model TF50KS-Y: NIPPON Paper Industries Co., Ltd.




    • Specification Notes:
    (1) Speed based on using 80 mm wide media only and Epson’s PS-180 power supply. Configurations not including the PS-180 will have a default print speed of 300 mm/sec.

    (2) Rated printhead and cutter lives based on use of the following media only, with printer operated at room temperature and normal humidity:
  • Model KT55FA: Papierfabrik August Koehler SE
  • Model PD160R: Oji Imaging Media Co., Ltd.
  • Model TF50KS-Y: NIPPON Paper Industries Co., Ltd.

    (3) Requires the use of a beacon dongle connected to TM-T88VI printer via the USB-A port. Supports only Apple® iBeacon™ compliant format. The Epson-approved dongle is Laird model BT820.

    (4) NFC tag requires use of a device that includes NFC reader, and may require additional software.
